EDM1IMX6U10R10E169377
EDM System-on-Module based on NXP i.MX6 DualLite with 1GB DDR3, 16GB eMMC and QCA9377 wireless/Bluetooth.
TechNexion EDM Type 1 SOM
Product Description
EDM System-on-Module based around NXP i.MX6 DualLite SoC with 1GB of DDR3 memory, 16GB eMMC storage, Gigabit LAN, Qualcomm Atheros QCA9377 Wi-Fi and Bluetooth.
Core System
| Processor Speed | 1.0 GHz |
|---|---|
| Architecture | ARM Cortex-A9 |
| Processor | NXP i.MX6 DualLite SoC |
| PMIC | NXP MMPF0100 |
| Memory | 1GB DDR3 |
| Storage | 16GB eMMC |
| Board-to-Board Connector | EDM connector (314-pin MXM3) |
| System on Module | EDM SOM |
| Debug Interface | JTAG interface by through-hole |
Connectivity
| Network LAN | 1x Atheros AR8035 Gigabit LAN |
|---|---|
| Wi-Fi | Qualcomm Atheros QCA9377 Wi-Fi 5 (802.11 a/b/g/n/ac) |
| Bluetooth | Qualcomm Atheros QCA9377 Bluetooth |
| Antenna | MHF4 connector |
Video and Audio
| Camera | MIPI CSI (2 lanes) |
|---|---|
| GPU Engine | Vivante GC320 (2D Composition); Vivante GC880 (Solo/DualLite) |
| Video Decode | 1080p30 + D1 (Solo/DualLite) |
| Video Encode | BP/Dual 720p |
| Audio Codec | On carrier board |
| Audio Interface | I²S (2 channel) |
Power and Software
| Power Input | 5V DC ±5% |
|---|---|
| Power Consumption | Depending on configuration |
| Standard Software Support | Linux, Yocto, Ubuntu, Android |
| Extended Software Support | Commercial Linux, Real Time OS |
Environmental and Mechanical
| Dimensions | 82 × 60 mm |
|---|---|
| Weight | 20 grams |
| Form Factor | EDM Type 1 |
| MTBF | 100,000+ hours |
| Shock | 15G half-sine, 11 ms duration |
| Vibration | 1 Grms random, 5–500 Hz, 1 hour/axis |
| Relative Humidity | 10–90% |
| Operating Temperature | Commercial: 0°C to +60°C |
Certification and Commercial Information
| Certification | FCC ID 2AKZA-QCA9377; IC 22364-QCA9377; EN 300 328 v2.2.2; EN 301 893 v2.1.1; EN 55032 / EN 55024; TELEC 201-180629; RCM compliant |
|---|---|
| Compliance | RoHS / REACH compliant |
| Bluetooth QDID | 150839 (Bluetooth 4.2); 193238 (Bluetooth 5) |
| Brand | TechNexion |
| Country of Origin | Taiwan |
| HTSN | 8473.30.1180 |
| ECCN | 5A992.c Mass Market |
Technical information transcribed from the original TechNexion product specification.
