TPS54540BDDAR SO-8 official package render

TI

TPS54540BDDAR - Texas Instruments Spennustillar – DC/DC rofastillar

Name: TPS54540BDDAR - Texas Instruments Spennustillar – DC/DC rofastillar
Brand: TI
Price: 2.23 USD
Availability: InStock

In stock

(0)

$2.23

Magnafsláttur

Quantity	Unit Price
1+	$2.22
10+	$1.97
30+	$1.81
100+	$1.51
500+	$1.44
1000+	$1.40

Eftir að þú hefur lagt inn pöntun mun söluteymi okkar senda skriflega staðfestingu á endanlegu verði, sendingarkostnaði og áætlaðan afhendingartíma. Aðflutningsgjöld, skattar, miðlunargjöld og önnur áfangastaðagjöld eru á ábyrgð viðskiptavinarins. Þegar þörf krefur getum við aðstoðað með tiltækar vöruupplýsingar og tollskjöl fyrir innflutningsskýrslu; endanleg tollafgreiðsla og greiðsla er áfram á ábyrgð viðskiptavinarins.

Integrated Circuit

TPS54540BDDAR

Buck Switching Regulator IC Adjustable 0.8V~41.1V 1 Output 5A SO-8

In Stock SO-8 normal

Unit Price$2.2231

In Stock

ManufacturerTI

PackageSO-8

Stock5000

PackTape & Reel (TR)

Basic Information

Manufacturer	TI
Manufacturer Part Number	TPS54540BDDAR
Description	Buck Switching Regulator IC Adjustable 0.8V~41.1V 1 Output 5A SO-8
IC Category	Voltage Regulators - DC DC Switching Regulators
Package	SO-8
Packaging	Tape & Reel (TR)
Standard Pack Quantity	2500
Available Stock	5000
Availability	In Stock
Lifecycle Status	normal

Key Specifications

Operating Temperature	-40℃~+150℃@(TJ)
Frequency - Switching	500kHz
Function	Step-down type
Number of Outputs	1
Features	Light load efficient mode;Frequency synchronization;Cycle-by-cycle current limiting;Overcurrent Protection
Output Type	Adjustable
Topology	Buck

Technical Attributes

Operating Voltage	4.5V~42V
Switch tube (built-in/external)	Built-in
Output Current	5A
Output Voltage	800mV~41.1V
Quiescent Current	146uA

Documents & Engineering Resources

Inventory, lead time, and pricing are updated regularly. Technical data is provided for engineering reference.

Datasheet PDF

Open datasheet PDF
