UCC5320ECDR - Texas Instruments Circuiti integrati RF
Regular price
$1.42
Dopo aver effettuato un ordine, il nostro team di vendita invierà una conferma scritta del prezzo finale, delle spese di spedizione e dei tempi di consegna stimati. I dazi doganali, le tasse, le commissioni di intermediazione e altre spese di destinazione sono a carico del cliente. Se necessario, possiamo fornire assistenza con le informazioni sul prodotto disponibili e i documenti doganali per la dichiarazione di importazione; lo sdoganamento finale e il pagamento restano a carico del cliente.
Couldn't load pickup availability
UCC5320ECDR
72ns 1 13.2V 72ns, 75ns 15V 75ns, SOIC-8 surface mount, adhesive mount
Available Stock: 235642SOIC-8Active
ManufacturerTexas Instruments
PackageSOIC-8
Stock235642
Standard Pack-
Pricing & Ordering
Unit Price$1.4217
Basic Information
| Manufacturer | Texas Instruments |
|---|---|
| Manufacturer Part Number | UCC5320ECDR |
| IC Category | RF Integrated Circuits |
| Package | SOIC-8 |
| Lifecycle Status | Active |
Technical Attributes
| Technology | Capacitive Coupling |
|---|---|
| Number of Channels | 1 |
| Voltage - Isolation | 3000Vrms |
| Common Mode Transient Immunity (Min) | 100kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 72ns, 75ns |
| Pulse Width Distortion (Max) | 20ns |
| Rise / Fall Time (Typ) | 12ns, 10ns |
| Current - Output High, Low | 2.4A, 2.2A |
| Current - Peak Output | 4.3A |
| Voltage - Forward (Vf) (Typ) | - |
| Voltage - Output Supply | 13.2V ~ 33V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40 degC ~ 125 degC |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Approval Agency | CQC, CSA, UR, VDE |
Inventory and pricing are updated regularly. Technical data is provided for engineering reference.
Datasheet
Download PDFMANUFACTURER ACCESS
